BWB XP - The Mixing Chamber

72
Replacing the Mixing Chamber
Release tabs
1. Remove the nebuliser from the mixing chamber.
2. Disconnect the gas tube from the mixing chamber.
3. Remove the U-Tube from the base of the mixing chamber.
4. Remove the mixing chamber by gently pulling back on the 2 release
tabs and pulling the mixing chamber in a downwards direction.
5. Replace the mixing chamber.
6. Reassemble the instrument in reverse order.
