A-4 cab Produkttechnik GmbH & Co KG
Modes of Operation
1. Print after label is removed
The printer is ready for this operation mode right away. It is not necessary
to configure the peripheral interface additionally. After removing a label
the next label is printed immediately and transported to the dispense
position :
The print of a label is executed if
- a print job is available
- there is no label waiting to be removed.
2. Print on demand with manual releasing
In this operating mode the connection of a dispense key to the peripheral
interface on the present sensor is necessary.
After removing the label, the printing of the next label will be executed by
pressing the dispense key.
The print of a label is executed if
- a print job is available
- there is no label waiting to be removed.
- the dispense key sends the START signal.
This operating mode requires that there is a contact between PIN13 (STA)
and PIN12 (GND).
3. Print on demand with releasing via an external control
In this operating mode, an external control is connected to the peripheral
interface on the present sensor.
After removing the label, the printing of the next label will be executed by
the signal from an external control device.
The print of a label is executed if
- a print job is available
- there is no label waiting to be removed.
- the external control sends the START signal.
This operating mode requires that there is a contact between PIN13 (STA)
and PIN12 (GND).
CAUTION !
The printer must be powered off before attaching a device (dispense key,
external control) for external activation of dispense mode !
Appendix A - Operation in Peel-off Mode
