84 cab Produkttechnik GmbH & Co KG
9. Test Options
ASCII Dump (Monitor) Mode
The ASCII Dump mode provides a method to print the control sequences sent
to the interface. In this mode the data received will be printed in text format
depending on the selected character set. Error messages will be printed
directly behind the fault, e.g. for unknown commands.
In this mode, the printer will not sense gaps between labels.
NOTICE !
The font used for the printout in this mode is large enough to be clearly
readable after facsimile transmission. For questions or future reference,
using this mode, you may print and retain a copy of the label data for each
label you print.
To get a printout in monitor mode, load media (labels, continuous paper) and a
transfer ribbon (if applicable), which extends over the entire print width of the
printer.
NOTICE !
If only small materials available then it is possible to cut the width of the
printout to at least 2 in (50mm). The value can be set using the parameter
''Width ASCII dump'' (see chapter Setup / Print Parameters).
1. Switch from "Online" mode to the Offline Menu by pressing the key.
2. Press the key or the key until the "Test" menu is displayed.
Press the key to confirm the selection.
3. Select the option "ASCII Dump Mode" by pressing the key or the key
and confirm the selection by pressing the key.
4. Start the ASCII Dump mode by pressing the key.
5. Send a print job to the printer.
6. The ASCII Dump mode printout will be printed with the heat level and print
speed set in the "Setup" menu.
7. In ASCII Dump mode, the printing of data will occur after four lines of data
has been received. In some cases, the last few lines of text have to be
printed by pressing the key.
8. To cancel the ASCII Dump mode printout, press the key.
9. Press the key to return to "Online" mode.
