CAB a3-2 User Manual

A-9cab Produkttechnik GmbH & Co KG
Fig. A-6 Example for an optical sensor with npn-output
Present sensor electronics
8
13
GND
STA
15
24P
1 XSTART
9 RXSTART
brown
white /
black*
blue
Sensor with npn-output
* dependent on the used sensor
Appendix A - Operation in Peel-off Mode
Fig. A-5 Example for an optical sensor with pnp-output
Present sensor electronics
8
13
GND
STA
15
24P
1 XSTART
9 RXSTART
brown
white/
black*
blue
* dependent on the used sensor
Sensor with pnp-output
