65cab Produkttechnik GmbH & Co KG
Parameter Meaning
Warn level Setting the threshold diameter for the
ribbon warning message "ribbon end"
Default : Off
Label sensor Method of label sensing
Default : Gap sensor
Tear-off mode Activating a small feed to the tear
plate at the end of a print job
Default : Off
Backfeed Method of backfeed when using peel-
off mode or the cut mode
Default : smart
Pause reprint Allows you to print additional labels
after finishing a print job by pressing
the key
Default : On
Error - Reprint Selection of automatically reprinting a
label after a correctable error has
been fixed.
Default : On
Width Setting the print width for ASCII dump
ASCII dump mode
Default : Automatic
Table 8d Overview of the "Print parameters" Menu (continuation)
Selection
Off
32 ... 74 mm
Gap sensor
Bottom reflect
Endless media
On
Off
smart
always
On
Off
On
Off
Automatic,
50mm to max.
print width
in steps of 5mm
Heat level
The "Heat level" parameter enables the printer to adapt to possible differences
in the thermal properties of the thermal printheads.
An adjustment has already been made in the factory. If the printhead must be
replaced, it is very likely the "Heat level" parameter will have to be adjusted.
To adjust the print for different print jobs, it is recommended that you make the
heat level adjustment with software. (e.g. for different materials and speed)
The heat level can be set using the software commands. The front panel value
and software command value will be totaled together when printing.
The setting of the "Heat level" parameter also affects the printer test prints (see
Test functions section).
8. Printer Configuration
