Initial Setup
3.4.2 Adjustingthetankoverowoat
Itisimportanttoverifythattheoatispositionedproperlyintheoverowcupbecauseitcanmovearound
intransportation.Ifthisoatisnotproperlyinplacetheswitchwillnotbeactivatedandtheunitwill
automaticallyshutdownsensinganoverowsituation.
ItisimportanttoverifythattheOverowcupisinplacewiththehighestsideinfrontandsecuredwell
with the green tape. If you need to remove this cup, please make sure that you replace it with the highest
sectionfacingthefrontandtheoverowtubeinthecup.Fastenitinplacewithtape.Thiswillensurethat
theoatwill“oat”andwillactivatetheoverowswitchifaproblemaccurs.
Location in the brewer
Hole in the exit of the tube
Cup
