AVALON GALLERIA Rev. 8 04/2013
www.cafection.com (800) 561-6162
20
INSTALLATION AND SERVICE MANUAL for AVALON Galleria and Quatro
3.12 Brewer and whipping system
3
1 2
1. Untight the screw that holds
the hoses support.
2. Remove the hoses support, (it will be
retained by the tubes). Disconnect
the coffee whipper wire (in the
back of the whipper protector).
3. Untighten the whipper
support screw.
