INSTALLATION AND SERVICE MANUAL for AVALON Galleria and Quatro
Cleaning & Sanitizing
5.6.2 Emptying the waste bin
Frequency: Daily or every 200 cycles
Aftereachcoffeecycle,thespentgroundsandusedlterpaperareautomaticallydiscardedintothewaste
binlocatedinthestand.Topreventthebinfromoverowingthereisanautomaticfunctionwhichstopsthe
brewer and shows the following message on the LCD screen:
The maximum setting = 399
The minimum setting = 0
Settingitto0willdisabletheautomaticfunctionandwillcauseanoverowproblemifthebinisfull.
The equipment will not dispense beverages until the bin is emptied and the counter is reset. To reset
the counter the brewer switch (#SW4) needs to be activated by being turned on and off. This factory set
counter can be adjusted to the waste bin size used. See the machine parameters for more instructions on
changing the setting.
How to empty the stand waste bin:
1. Open the stand door located directly below the brewer;
2. Cutthelterpaper4“belowthedrumwithscissorsorteargently;DONOTYANKONTHEPAPER!
3. Removethelledplasticbagfromthespentgroundsbinandreplacewithanewone;
4. Activate the brewer switch (#SW4) by turning it on and off (right then left).
How to empty the brewer waste bin:
1. Open the brewer door;
2. Take the front panel off;
3. Activate the brewer switch (#SW4) by turning it off (to the left);
4. Cutthelterpaper4”belowthedrumwithscissorsorteargently;DONOTYANKONPAPER!
5. Activate the brewer switch (#SW4) by turning it on (to the right);
6. Replace the front panel and close the door.
Itisveryimportantnottoyankonthelterpaper.Doingsomaypreventthe
brewer from functioning properly.
Needs Service
Activate Brewer
