INSTALLATION AND SERVICE MANUAL for AVALON Galleria and Quatro
4.3 Electronic key option
Free mode
Apply a programmed electronic key onto the electronic socket. This should be shown on the
screen:
Order the beverage of your choice by following the steps in the previous «Test mode»
Press on the «format» button on the user’s panel. This should be shown on the screen:
Multi-cup mode
Apply a programmed electronic key onto the electronic socket, this should be shown on the screen:
Press on the «strength» button on the user’s panel. This should be shown on the screen:
Makeyourselectionfollowingstepsinthesection«Testmode».Press«start»toconrm.
5 CLEANING AND SANITIZING
5.1 Automatic rinsing function
A new function is added to our apparatuses to make easier the rinsing of the interior components (brewer,
whipper).
Instructions to follow:
1. Install a container that could contains at least 20 OZ of liquid; vat.
2. Press on the black setup button (sw1) on the main board;
3. Close the door;
4. Press on the hidden key;
5. Press on Start;
6. Waituntilthecycleisnished;
7. Rinse again if it is needed, or press on start to exit.
Service Software
Choice special mode
Format=Free, STRG=multi
--------Freemode!--------
Choice special mode
Format=Free, STRG=multi
----Multi-cupmode!----
* Make your choice *
