INSTALLATION AND SERVICE MANUAL for AVALON Galleria and Quatro
Initial Setup
3 INITIAL SETUP
Before you install the brewer on location, we strongly suggest that it be unpacked, inspected and bench
tested before it leaves your warehouse.
3.1 On-site installation requirements
3.1.1 Operating environment
For indoor use only.
3.1.2 Power supply
Make sure each unit has its own electrical circuit and is located within 6 feet of the dedicated electrical
outlet.
Use only a polarized grounded receptacle.
Domestic 115 VAC / 60 Hz - 15 A Circuit.
3.1.3 Water supply
Should be a plastic 1/4” or 3/8’’ O.D. dedicated line branched off a larger line. An easily accessible shut
off valve up stream of the unit is highly recommended for ease of installation. Water pressure should be at
least 20 PSI and no more than 80 PSI
3.1.4 Tools required
#2 Phillips screwdriver
Regular medium pliers
Adjustable wrench
Level indicator
Other tools may be required depending on the type of water supply
tubing and location.
3.1.5 Clearances
Machine Clearance Necessary for :
Height 44” 50” Opening the top of the machine.
Width 18 1/2” 26” Per side. Key access on one side and door swing on
the other.
Depth 26” 26 1/2” In front when the door is open.
Other
clearance
1.5”
6”
Clearance of water hookup, hoses and adequate air
circulation
Neededonlyifaltrationsystemisinstalledbehindthe
machine
See footprint and waste chute position in annex 4 and 5.
