INSTALLATION AND SERVICE MANUAL for AVALON Galleria and Quatro
Initial Setup
3.16 Programming tips
Reminder
Please refer to the main board diagram and description in section 3.15 to better visualise the procedures.
To program the product prices and values follow these steps:
1. Unlock and open the door of the equipment
2. Press the SETUP button located on the lower section of the main board (#SW1) The LCD will indicate:
3. Keep this in mind for the following steps: (refer to overlay)
Cafe Vanilla: Yes / +
Cafe Latte: No / -
Strength: Next Menu / rigth arrow
Size: Previous Menu / left arrow
Chocolate: Next Window / right arrow
Mokaccino Previous Window / left arrow
Start:  Conrmchange/Exit
* If you wait more than 45 seconds without pressing on anything you will exit automatically
the menu and you will have to start over.
4. Start by pressing on Coffee #1 on the keypad. This is what should be indicated:
Press on «start» if you do not want to change this option and move to the next. If you wish to put this
product unavailable press on the «cafe vanilla» button, when the change has been done, press on «start»
toconrm.
5. This is what should now be indicated on the screen:
Press on «chocolate» to move to the right character that you want to change, press on «french vanilla»
to increase the price or «cafe vanille» to decrease the price, when the price has been changed, press on
«start»toconrm.
6. This is what should now be indicated on the screen:
Press on the «chocolate» button to move to the right character that you want to change, press on «french
vanilla» to increase the value or «cafe vanilla» to decrease the value, when the value has been changed,
presson«start»toconrm.
7. Follow these steps for the large coffee #1 regular, small coffee #1 strong, large coffee #1 strong. Then
press on the «hot water» button until you see this screen:
8. Follow steps 4 through 7 for the other beverage selections.
Setup mode
Press START to exit
Sm Coffee #1 Rg
Price $0.00
Sm Coffee #1 Rg
Product available
Sm Coffee #1 Rg
Quantity 000
Setup mode
Press START to exit
