Initial Setup
3.9 Driptrayandoverowinstallation
3.9.1 Overowdriptrayinstallation
1. Screwtheoverowdriptraysupport(05CAB11)
under the base of the brewer using the 2 screws
included.
2. Take out the 2 wires with connectors found
inside the brewer using the chute hole and connect
themtothe2connectorsoftheoverowdriptray
(05ASS30).
3. Puttheconnectedoverowdriptray(05ASS30)
on its support (05CAB11).
05ASS30
05CAB11
Installtheoverowdriptray
from inside the equipment.
