INSTALLATION AND SERVICE MANUAL for AVALON Galleria and Quatro
Cleaning & Sanitizing
5.7.2 Soluble canisters
Removing whipping assembly for cleaning
Frequency: Weekly or every 200 cycles
If there is residue, remove the assembly for manual cleaning under hot water:
1. Remove the tube from the base;
2. Lift off the funnel and twist off the whipper base;
3. Rinse thoroughly under hot water and use tube brush if necessary for tubing
area;
4. Air dry completely;
5. Reinstall all parts in the reverse order.
6. Orderalargebeveragetoconrmthatallpartsorswitcheshavebeen 
replaced.
Removing canisters for cleaning
Frequency: Monthly or every 1,000 cycles
To ensure a consistent product quality, we recommend removing and
emptying the canisters on a monthly basis. This will ensure that the
product does not adhere to the walls of the canister.
1. Unlock the door;
2. Remove the top cap of the machine;
3. Pull the canister through the top of the brewer to disengage it from the motor
and transmission;
4. Clean and sanitize under hot water and air dry completely;
5. Reinstall all parts and reload products in the reverse order;
6. Orderalargebeveragetoconrmthatallpartsorswitcheshavebeen 
replaced.
5.7.3 Whipper
To remove the assembly of the whipper for cleaning
Frequency: Weekly magazine or every 200 cycles
1. Refer to page 20-21
2. Remove the base of the whipper
3. Rince under hot water
4. Let dry with the free air;
5. Reinstall all the parts in the opposite order;
6. Orderalargebeveragetoconrmthatallthepartsareinplace.
