Calix ODC-10 Installation Guide
105
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© 2001-2003 Calix. All Rights Reserved.
Appendix: Specifications
ODC-10 specifications
Specifications
Wired Capacity
Copper: up to 240 lines
Fiber: up to 240 lines
Any copper/fiber combination up to 240 lines
Dimensions 38"W X 33"D X 45"H
Weight 500 lbs.
(Equipped with Dynasty 80 Ah batteries: 700 lbs.)
Environmental Ambient Temperature:
-40 C to +52 C (per GR-487)
Cooling
Integrated air-to-air tubular cooling system with DC blowers
Power 220-240 VAC single phase: 30 Amp service with UL listed service disconnect
Redundant AC feeds to rectifier
Redundant DC feeds to Calix C7 shelf
Low voltage DC disconnect (-42 V)
High power AC surge protection (Joslyn)
DC Rectifiers
Standard DC rectifier: Calix (Delta)
Battery Back-Up
Preferred batteries: Dynasty 80 AH battery
One string per cabinet
Option for extended battery tray configuration
