Calix ODC-10 Installation Guide
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© 2001-2003 Calix. All Rights Reserved.
Site requirements
Cabinet pad footprint
The Calix C7 ODC-10 cabinet pad footprint measures 74" wide x 80" deep - the minimum
dimension for the concrete pad. The drawing below shows the proper placement of the
cabinet on a concrete pad.
Click to view a larger image.
