0
17
24
FR
1
2
3
4
SP
0
L N
E1 EX W
24V 0
10 11 TS 1 2
L1T L2T CT VS VF
+ STB -
E1 EX W
24V 0
10 11 TS 1 2 3 3P 4 5 7 CX CY CZ
A B GND
COM
COM
NC
NC
+
-
CAME
U V W CAPACITOR
FC FA F
+ E -
0
FR
1
2
3
4
SP
L1T L2T CT VS VF
p.
11 - Manual code:
119BJ04EN v.
1 02/2015
© CAME Cancelli Automatici S.p.A. - The data and information in this manual may be changed at any time and without notice..
Power supply
Terminals for powering 24 V AC - max
20 W accessories
Power supply 230 V AC
frequency 50/60 Hz
Gearmotor 230 V AC
Factory wiring
Warning devices
Gate open warning light (Contact rating: 24 V - 3 W max).
Warns about the gate status, see function F 10.
Movement flashing light (contact rating: 230 V - 25 W max). It flashes when the gate is
either opening or closing.
Cycle or courtesy light (contact rating: 230 V - 60 W max).
Auxiliary connection of an outdoor light which can be positioned where you like, to increase
lighting in the driveway/parking area.
Cycle: it stays lit from the moment that the gate leaf starts opening until it is completely
closed (including the automatic closing time).
Courtesy: it stays on for an adjustable time of between 60 to 180 seconds.
Red
White
Green
White
Orange
White
Red
Black
Grey
Brown
Blue
Orange
Condenser
Limit switch
Brown
Encoder
Motor torque limiter
To vary the motor torque, move the shown faston (the one with the black wire) to one of the 4 positions: 1 min – 4 max.
The gearmotor is already connected.
To install on the right, Invert the gearmotor (U-V) and (FA-FC) endstop phases.
Black
