STYLO-BS
STYLO-BD
106
80
437,5
630
640
57
330
323
Dimensions
Page
5 - Manual FA01806-EN - 01/2024 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. - Translated original instructions
Technical data
Type
STYLO ME - STYLO RME
Protection rating IP54
Power supply 230 V AC (50/60 Hz)
Motor power supply 24 DC (50/60 Hz)
Current draw (max) 5 A
Power 48 W
Maximum torque 100 Nm
Opening time (90°) adjustable
Duty cycle (%) intensive use
Operating temperature (°C) -20 - +55
Storage temperature (°C) -20 - +70
Average life (cycles) 120,000
Gear ratio 1/531
Weight (kg) 6.8 kg
The average product life is a purely indicative estimate. It applies to compliant usage, installation and maintenance
conditions. It is also infl uenced by other factors, such as climatic and environmental conditions.
Before installing the product, keep it at room temperature where it has previously been stored or transported at a very
high or very low temperature.
