M N ENC EB
EB ENC N M
M N E EB
M N E EB
M1
ZL92
M2
1
1
M1 N1 ENC1 EB1 M2 N2 ENC2 EB2
Page
12
12 - Manual FA01806-EN - 01/2024 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. - Translated original instructions
Open the lower cap and make the necessary electrical connections.
Complete installation by closing the lower cap again.
Cut o mains power and open the protective trap door for release. Insert the
key and turn it.
MANUAL RELEASE OF THE NON-REVERSIBLE GEARMOTOR
ELECTRICAL CONNECTIONS
24 V (DC) gearmotor with
delaying closing action
24 V (DC) gearmotor with
delaying opening action
Electrical connection of the STYLO ME gearmotor to the control panel
