CAME STYLO User Manual

M N E EB
M N E EB
M1
ZL92
M2
1
1
M1 N1 ENC1 EB1 M2 N2 ENC2 EB2
STYLO-BS STYLO-BD
A
D
A
D
90
~
i
C
C
Page
13
13 - Manual FA01806-EN - 01/2024 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. - Translated original instructions
24 V (DC) gearmotor with
delaying closing action
24 V (DC) gearmotor with
delaying opening action
Electrical connection of the STYLO RME gearmotor to the control panel
Examples of applications
INSTALLING AND CONNECTIONS FOR OUTER OPENING
Following, are the only things that change compared to a standard installation:
Gate-leaf
opening (°)
A (mm)
i (mm)
C (mm) D (mm)
90 90 285 0 450
90 180 210 0 450
120 90 125 0 450
Gate-leaf
opening (°)
A (mm) C (mm) D (mm)
90 90 0 400
