60
PART 9 TROUBLESHOOTING
COMPONENT
FAILURE MODE
ANALYSIS
Incoming Power • Two wires interchanged
• No effect on safety
• Live and Neutral wires are interchanged
Transformer
Tripped
• The 24 Volts and 120 Volts wired
are interchanged
• Alert: 49
• Lockout: 53
• Breaker on transformer trips
Relief Valve
• System pressure exceeds relief
valve setting
• Replace the standard relief valve with a higher rated valve up to the
maximum pressure of the heat exchanger
• Improperly sized expansion tank
Flow Switch
Flow Switch contacts are open
Alert: 63, 275-281, 460
• LCI OFF
Ensure pump is operating
Ensure all valves are open and there is no obstruction in boiler piping
Ensure all air has been purged from the system
Verify that wiring is correct
Water Pressure
Switch
Pressure Switch contacts are open
• Alert: 63, 275-281, 460
• LCI OFF
• Verify that minimum water pressure exceeds 12 PSI
Ensure pump is operating
Ensure all valves are open and there is no obstruction in boiler piping
Ensure all air has been purged from the system
• Verify that wiring is correct
Flame Failure
• The boiler has failed to ignite the
burner
• Alert: 110, 291-294
To reset the module, refer to section 5.9
Verify that all air has been purged from gas line
Inspect Hot Surface Igniter and related wiring for damage and
connection errors
AR1000-2500: Verify igniter is glowing
AR3000-4000: Verify pilot is lit
Inspect UV Scanner and associated wiring. Replace if necessary
Remove the detector and clean the viewing window with a soft, clean
cloth
Clean the inside of the sight pipe before re-installing the detector
Verify that boiler is properly grounded
Verify incoming gas supply pressure and that it coincides with Table 7
Verify that the vent/air inlet piping (if equipped) are correctly installed
and obstructions are not present
Verify 24 VAC is being supplied to the Low-End Gas Valve relay from
the Avenger Controller during ignition. Check wiring from Avenger
Controller and Gas Valve Relay. If a signal cannot be detected, the
Avenger Controller needs to be replaced
If 24 VAC is present, check the outlet of the valve to ensure that gas is
flowing. When the valve is energized a change in pressure should
occur, if no change is detected the gas valve has failed to open or it is
passing insufficient amount of gas. If this is an initial startup increase
the low fire gas setting by ¼ turn clockwise
Inspect the burner. Refer to Burner Maintenance in section 10.5
Replace the Controller, if necessary
Flame Disappears
During a Run
Cycle
The Avenger
boiler was running,
and flame signal suddenly
disappeared.
Lockout: 106, 107, 108, 109
Verify that all air has been purged from gas line
Verify that boiler is properly grounded
Inspect UV Scanner and associated wiring. Replace if necessary
Remove the detector and clean the viewing window with a soft, clean
cloth
Clean the inside of the sight pipe before re-installing the detector
Adjust the blocked flue switch. Turn clockwise to reduce sensitivity
Verify incoming gas supply pressure and that it coincides with Table 7
Verify that the gas line connections to the boiler are adequate. Refer to
Table 6
Verify that the vent/air inlet piping (if equipped) are correctly installed
and obstructions are not present
Verify that 24 VAC is being supplied to the Low-End Gas Valve during
operation. If a signal cannot be detected, the transformer needs to be
replaced
Verify that 115 VAC is being supplied to the High-End Gas Valve
during operation
Inspect the burner. Refer to Burner Maintenance in section 10.5
Replace the Avenger Controller, if necessary
