4
1.4.2 END OF SEQUENCE
1. Set point temperature is reached.
2. Power to the gas valve is turned off.
3. Combustion air fan ramps to a stop over the factory pre-programmed time period.
4. Thermostat is now in a standby mode waiting for the next “Call for Heat”.
To minimize the possibility of serious personal injury, fire or damage
to your appliance, never violate the following safety rules.
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE can cause injury or property damage.
Refer to this manual. For additional information, consult a qualified installer, service agency or gas supplier.
Do not use this appliance if any part of it has been under water. The possible damage to a flooded appliance can be extensive and
present numerous safety hazards. Any appliance that has been under water must be replaced.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance. Do not touch any electric switch. Do not use any phone in your building. Immediately call your gas
supplier from a neighbor’s phone. Follow the gas supplier’s instructions. If you cannot reach your gas supplier, call the fire
Consult and follow local Building and Fire Regulations and other Safety Codes that apply to this installation. Contact the local gas
utility company to authorize and inspect all gas and flue connections.
Installation and service must be performed by Camus Hydronics Limited qualified factory trained service technicians.
Should overheating occur or the gas supply fails to shut off, DO NOT turn off or disconnect the electrical supply to the pump. Shut off
the gas supply at a location external to the appliance.
Boilers and water heaters are heat producing appliances. To avoid damage or injury, do not store materials against the
appliance or the vent-air intake system. Use proper care to avoid unnecessary contact (especially children) with the appliance
and vent-air intake components.
• Never cover your appliance, lean anything against it, store trash or debris near it, stand on it or in any way block the flow of fresh
air to your appliance.
• UNDER NO CIRCUMSTANCES may flammable materials such as gasoline or paint thinner be used or stored in the vicinity of
this appliance, vent-air intake system or any location from which fumes could reach the appliance or vent-air intake system.
• A gas appliance that draws combustion air from the equipment room where it is installed must have an adequate supply of fresh
air circulating around it during burner operation for proper gas combustion and proper venting.
1.5 CODES
The equipment shall be installed in accordance with those installation regulations enforced in the local area where the
installation is to be made. These shall be carefully followed in all cases. Authorities having jurisdiction shall be consulted before
installations are made. In the absence of such requirements, the installation shall conform to the latest edition of the National Fuel Gas
Code, ANSI Z223.1 and/or CAN/CGAB149 Installation Code. All electrical wiring must be done in accordance with the requirements of
the authority having jurisdiction or, in the absence of such requirements, with National Electrical Code, ANSI/NFPA70 and/or the Canadian
Electrical Code part 1 CSA C22.1. Where required by the authority having jurisdiction, the installation must conform to the American
Society of Mechanical Engineers Safety Code for Controls and Safety Devices for Automatically Fired Boiler, ANSI/ASME CSD-1. All
boilers conform to the latest edition of the ASME Boiler and Pressure Vessel Code, Section II & IV. Where required by the authority having
jurisdiction, the installation must comply with the CSA International, CAN/CGA-B149 and/or local codes. This appliance meets the safe
lighting performance criteria with the gas manifold and control assembly provided, as specified in the ANSI standards for gas-fired units,
ANSI Z21.13 & ANSI Z21.10
1.6 WARRANTY
• Factory warranty (shipped with unit) does not apply to units improperly installed or improperly operated.
• Factory warranty shall apply only when the appliance is installed in accordance with local plumbing and building codes,
ordinances and regulations, the printed instructions provided with it and good industry practices.
