Camus Hydronics Avenger Series - Specifications and Dimensional Data

8
1.11 SPECIFICATIONS AND DIMENSIONAL DATA
Table 3: Appliance Dimensions and Specifications
Model
A
(in.)
B (in.) C (in.) D (in.) E (in.) F (in.) G (in.) H (in.) I (in.) J (in.) K (in.) *L (in)
COG
(A)
COG
(B)
1000
29 1/2
34
83
51 1/2
14 7/8
53 7/8
67 1/8
5
10 1/4
9 3/8
11 3/4
74 1/8
40
14.5
1500
29 1/2
38
83
52 3/8
14 7/8
54 1/2
68
3 1/2
10 7/8
8 1/8
10 1/2
74
38.5
15
2000
35
44
90
52 7/8
17 1/2
57 1/4
73 1/2
5 5/8
10
10 1/8
13 1/4
78 1/2
42
17.75
2500
35
44
90
52 7/8
17 1/2
57 1/4
73 1/2
5 5/8
10
10 1/8
13 1/4
78 1/2
42
17.75
3000
35
44
90
52 7/8
17 1/2
52 1/4
73 1/2
5 3/4
10 1/4
9
13
79 1/8
55
18.5
3500
35
44
99
53 3/8
17 1/2
60
77
5 1/2
10
8 1/2
16
83 1/2
43
18
4000
35
44
99
53 3/8
17 1/2
60
77
5 1/2
10
8 1/2
16
85 1/2
43
18
Model
COG
(C)
M (in.) N (in.) P (in.)
Qw
(in)
Qh
(in)
R (in.) *S (in.) T (in.) U (in.)
W (in.)
Ø Water
X (in.)
Ø Gas
Y (in) Ø
air
Weight
(lbs)
1000
13.5
3 7/8
16 7/8
18 7/8
24
74
33 1/4
18 1/2
3 1/2
5 3/8
2
1
8
1180
1500
15
4
17 7/8
19 3/8
24
74
36 1/2
20 1/2
3 1/2
5 3/8
2 1/2
1 1/4
10
1530
2000
17
4
20
24
28
81
42 1/2
23 1/4
3
5 3/8
3
1 1/4
12
2085
2500
17
4
20
24
28
81
42 1/2
23 1/4
3
7 5/16
3
1 1/2
12
2150
3000
20
4
20
24
28
81
42 1/2
24 1/8
3 1/2
7 5/16
3
1 1/2
12
2400
3500
17
6 1/2
20 1/2
24
27
90
42 1/2
24
4
7 5/16
4
2
12
2520
4000
17
6 1/2
20 1/2
24
27
90
42 1/2
24 1/2
4
7 5/16
4
2
12
2620
*Direct Vent/Sealed combustion option COG-Center of Gravity
Model
Required Ø for
up to 100 ft.
equiv. length for
Direct Venting
(in)
Vent connection
Ø, as shipped (in)
Required Category
IV, vent Ø up to
100 ft. equiv.
length (in)
Required Category II
vent Ø (in)
Blower air inlet Ø
(in)
AR(N,P)-1000
6
6
6
7
5 3/8
AR(N,P)-1500
6
8
7
8
5 3/8
AR(N,P)-2000
8
9
8
10
5 3/8
AR(N,P)-2500
8
9
9
10
7 5/16
AR(N,P)-3000
10
10
9
10
7 5/16
AR(N,P)-3500
10
10
10
12
7 5/16
AR(N,P)-4000
10
10
10
12
7 5/16
