Camus Hydronics Avenger Series - Page 85

80
BLOWER & BURNER ASSEMBLY
ITEM
#
FIGURE (S)
Part Description Part Number
Avenger Models
All
1000
1500
2000
2500
3000
3500
4000
1 B Hot Surface Igniter 873-01045-000 x
2 B UV Scanner 817-00654-000 x
3 B Graphite Gasket
853-09540-000 x
853-09541-000 x x x
853-09554-000 x x x
4 B Red Silicone Gasket
853-09544-000 x
853-09543-000 x x x
853-09552-000 x x x
5 B
White Ceramic Gasket with
Graphite Facing
853-09545-000 x
853-09542-000 x x x
853-09553-000 x x x
6 B Burner Flange
125-00518-000,
(4”)
x
125-00507-000,
(8”)
x x x
125-01464-000,
(10”)
x x x
7 B Hot Surface Igniter Mounting Plate 285-03646-000 x
8 B
Primary Burner (incl. Burner
Flange)
829-20004-001
(4”)
x
829-20005-001
(5-1/2”)
x
829-20006-001
(8”)
x
829-20007-001
(8”)
x
829-20008-001
(10”)
x
829-20009-001
(10”)
x x
9 B Aluminum Fan Flange
285-03640-000 x
285-03642-000 x x x
285-03644-000 x x
285-03643-000 x
10 B Blower
813-02895-000
(1HP)
x
813-02896-000
(1.5HP)
x x
813-02897-000
(3HP)
x
813-02898-000
(3HP)
x x
813-02899-000
(5HP)
x
11 B Sight Glass 851-06444-000 x
12 B Sight Glass Holder 285-03645-000 x
13 B
Air Inlet Damper Assembly 427-25026-000 x x x
(Includes Siemens Electronic Damper
Actuator)
427-25028-000 x x x x
