7. While firmly holding the Printhead you have removed, use your other hand to remove the orange Protective Part (a).
Squeeze the grips (c) of Protective Part (b) and pull it down to remove it.
Important
• The inside surface of the Protective Part (a) and Protective Part (b) is coated with ink to protect the
nozzles. Be careful not to touch these surfaces when removing the caps.
• The Printhead contains ink to protect the nozzles. We recommend removing Protective Part (b) as you
hold it over the Printhead package or safely out of the way to avoid spilling ink and staining your
clothes or the surrounding area. If ink accidentally spills, wipe off the ink with a dry cloth.
• Do not reattach the Protective Part or protective material. Dispose of these materials in accordance
with local regulations.
8. With the nozzles facing down and the metal contacts toward the back, insert the Printhead into the Carriage. Careful-
ly push the printhead firmly into the Carriage, ensuring that the nozzles and metal contacts do not touch the carriage.
9. Pull the Printhead Fixer Cover down toward the front to lock the Printhead in place.
Maintenance
>
Printheads
>
Replacing the Printhead iPF655
11
802
