Canon imagePROGRAF iPF680 User Manual

2
In the Media Type list, select the name of the media to
switch off or on for display.
Click the Show/Hide button.
The selected paper is alternately shown or hidden.
Note
• You can select multiple paper.
• The names of media switched for non-display appear grayed out in the Media Type list.
• Each time you click the Show/Hide button, the display mode cycles from showing both the printer driver and
printer panel, to hiding both the printer driver and printer panel, and then to showing only the printer panel.
3
In the Edit Media Types dialog box, click the Update
button.
4
The Confirm Update dialog box is displayed.
Configure Update Target and click the Execute button.
Communication with the printer begins.
Note
• You should normally select Update the printer control panel and printer driver.
Switching Media Types Display Show/Hide iPF680
User's Guide
Handling and Use of Paper Media Conguration Tool (Mac OS)
430

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
