Canon imagePROGRAF iPF680 User Manual

Menus are displayed with the upper line selected. You can use the buttons on the Control Panel to access each menu.
• Press Back button to access a higher menu in the menu list, and press OK button to access a lower one.
• Press ▲ to access a higher menu in the menu list, and press ▼ to access a lower one. If items of the menu list
are more than the lines of the screen, press ▲ and ▼ to scroll the menu. Items you select are highlighted.
The scroll bar at right indicates the current position in the overall menu.
• Lower menus are available if is displayed at left next to the second and subsequent rows. To access the lower
menus, select the menu and press the OK button.
Menu Operations
iPF680
User's Guide
Control Panel Printer Menu
448

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
