Canon imagePROGRAF iPF680 User Manual

Ink Menu
Setting Item Description, Instructions
Rep. Ink Tank Replace the Ink Tank at this point. Follow the instructions dis-
played to complete the required procedure. (See "Replacing Ink
Tanks.") ➔ P.540
Head Cleaning A Printhead cleaning options. (See "Cleaning the Print-
head.") ➔P.550
Execute Head Cleaning A if printing is faint, oddly colored, or
contains foreign substances.
Job Menu
Setting Item Description, Instructions
Job Log (Choose from information
about the last three print jobs.)
Document Name Indicates the document name
of the selected print job.
User Name Indicates the name of the user
who sent the print job.
Page Count Indicates the number of pages
in the job.
Job Status Indicates the printing results.
Print Start Time Indicates when the print job
was started.
Print End Time Indicates when the print job
was finished.
Print Time Indicates the time required to
print the job.
Print Size Indicates the paper size in the
print job.
Media Type Indicates the type of paper in
the print job.
Interface Indicates the interface used for
the print job.
Ink Consumed Indicates a rough estimate of
how much ink was consumed
per job.(*1)
Print settings A counter for maintenance pur-
poses. Indicates job print set-
tings.
Head Height A counter for maintenance pur-
poses. Indicates the head
height when jobs wereprinted.
Temp./Humidity A counter for maintenance pur-
poses. Indicates the tempera-
ture and humiditywhen jobs
were printed.
Adjustment req. A counter for maintenance pur-
poses. Indicates adjustment
conditions appliedto jobs.
Menu Settings iPF680
User's Guide
Control Panel Printer Menu
458

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
