Canon imagePROGRAF iPF680 User Manual

Setting Item Description, Instructions
Print Job Log Print a record of print jobs, in-
cluding the paper type and
size, amount of ink consumed,
and so on. Ink consumption in-
dicates a rough estimate of the
amount of ink consumed per
print job.(*1)
Pause Print Choose On to stop printing.
*1: A rough estimate of the amount of ink consumed per print job is displayed. Actual ink consumption may be different. The aver-
age margin of error for estimates calculated according to Canon measurement conditions for ink costs is ±15%. Canon does not
guarantee the accuracy of these estimates. Estimates may vary depending on conditions of use. Calculation of these estimates
does not include ink consumed when cleaning printheads by forceful ejection of ink.
Set./Adj. Menu
Limited items are displayed during printing. The displayed items are indicated by annotations.
Setting Item Description, Instructions
Test
Print
Nozzle Check Print a test pattern to check the nozzles.
Status Print Print information about the setting values and condition of
the printer.
Interface Print Print interface settings information.
GL2 Set Print Print the settings as specified in GL2 Settings.
Paper Details Print the paper settings as specified in Paper Details.
Print Job Log Print a record of print jobs, including the paper type and
size, amount of ink consumed, and so on. Ink consumption
indicates a rough estimate of the amount of ink consumed
per print job.(*1)
Menu Map Print the menu structure.
Color Palette Print the GL2 color palette.
Adjust
Printer
Head
Posi.
Adj.
Auto(Standard) The printer prints and reads a test pattern for automatic ad-
justment of Printhead alignment relative to the printing di-
rection. (See "Automatic Adjustment to Straighten Lines and
Colors.") ➔P.524
Auto(Advanced) The printer prints and reads a test pattern for automatic ad-
justment of Printhead alignment relative to the printing di-
rection and spacing between nozzles and colors. (See "Au-
tomatic Adjustment to Straighten Lines and Col-
ors.") ➔P.524
Manual Print a test pattern for adjustment of Printhead alignment
relative to the printing direction. Enter the adjustment value
manually based on the resulting pattern. (See "Manual Ad-
justment to Straighten Lines and Colors.") ➔ P.525
Head Inc. Adj. Print a test pattern for adjustment of the Printhead orienta-
tion. (See "Adjusting Line Misalignment.") ➔ P.527
Feed
Priority
Adj. Pri-
ority
Automatic Specify exact paper feeding, if desired. Normally, select Au-
tomatic. Choose Print Quality for attractive printing.
Choosing Print Quality also makes banding less noticea-
ble. Choose Print Length if you prefer to feed the paper an
exact amount.
Print Quality
Print Length
Adj.
Quality
Auto(GenuinePpr) Specify this mode with paper identified in the Paper Refer-
ence Guide. (See "Displaying the Paper Reference
Guide.") ➔P.363
iPF680 Menu Settings
User's Guide
Control Panel Printer Menu
459

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
