2 Press the OK button.
The Paper Menu is displayed.
3 Press ▲ or ▼ to select Paper Details, and then press the OK button.
4 Press ▲ or ▼ to select the type of paper, and then press the OK button.
Note
•
When VacuumStrngth is set to Automatic, the setting value selec-
ted for the previous print job is displayed (to the right of Automatic )
once you select the type of paper currently supplied.
However, the value is cleared when the printer is turned off or the pa-
per is replaced.
5
Press ▲ or ▼ to select VacuumStrngth, and then press the OK button.
6
Press ▲ or ▼ to select the desired setting value, and then press the OK button.
Adjusting the Vacuum Strength iPF680
User's Guide
Adjustments for Better Print Quality Adjusting the feed amount
538

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
