Canon imagePROGRAF iPF680 User Manual

3
Using a damp cloth that you have wrung out completely, wipe
inside the Top Cover to clean it. Wipe away any ink residue
on the Platen as a whole (a), the Paper Retainer (b), Border-
less Printing Ink Grooves (c), and Ejection Guide (d).
Warning
• Never use flammable solvents such as alcohol, benzene, or thinner. If these substances come into contact
with electrical components inside the printer, there is a risk of fire or electrical shock.
Important
• Do not use a dry cloth to wipe inside the Top Cover. This may create a static charge, which may attract dust
and affect the printing quality.
•
Do not touch the Linear Scale (a) or Carriage Shaft (b). This
may stain your hands and damage the printer.
Cleaning Inside the Top Cover
iPF680
User's Guide
Maintenance and Consumables Cleaning the Printer
566

Canon imagePROGRAF iPF680 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 609.6 mm
Media width (sheets)	203.2 - 609.6 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Plain paper, Roll
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Certification	RoHS
Product color	Black, Grey
Sound pressure level (printing)	47 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	757 mm
Width	997 mm
Height	507 mm
