Handling rolls
5. While holding the edge of the roll paper , lift the Release Lever .
6. Hold the roll edge as you gently pull it evenly to the position of the Ejection Guide (a) using the
both hands. Align the right side of the roll paper with the Paper Alignment Line (b) so that the
paper side is parallel to the line and lower the Release Lever .
Important
• Be sure to follow steps 5 and 6. If paper cannot be advanced straight or if it wrinkles, it may jam or
rub against the Printhead .
• Do not force the roll paper into alignment with the Paper Alignment Line (b). This may prevent the
paper from being advanced straight.
Note
• Y ou can adjust the strength of vacuum holding paper against the Platen when the Release Lever
is open. If it is dif cult to load paper , press the ▲ or ▼ button on the Control Panel to adjust the
strength. Set vacuum stronger by pressing the ▲ button or weaker with the ▼ button. Three
settings are available.
182 Handling Paper
