Printheads
Replacing the Printhead
Follow the steps below to replace the Printhead . Failure to follow this procedure may cause ink to leak
from the Printhead , resulting in stains.
Only remove or install the Printhead after selecting Replace P .head in the menu, and follow the instructions
on the panel. Removing or installing the Printhead without following the correct procedure may damage the
Printhead .
Note
• Prepare a new Ink T ank when ink levels are low .
• Y our hands may become dirty during Printhead replacement. During replacement, wear the gloves
provided with the new Printhead .
• Choose On in Auto Print to have the printer automatically adjust the Printhead alignment after
Printhead replacement. ( → P .48)
1. If the roll is not ejected because of the cutting method selected, cut it manually and remove it.
( → P .486)
2. Clean inside the T op Cover . ( → P .718)
3. Press the Menu button to display MAIN MENU .
4. Press ▲ or ▼ to select Maintenance , and then press the ► button.
5. Press ▲ or ▼ to select Replace P .head , and then press the ► button.
6. Press ▲ or ▼ to select Y es , and then press the OK button.
Select Printhead L when replacing Printhead L and Printhead R when replacing Printhead R .
When replacing both, select L & R Printheads . Be sure to specify the correct Printhead.
Ink is now absorbed.
After about three minutes, a message is shown on the Display Screen instructing you to open
the T op Cover .
7. Open the T op Cover .
Instructions are now shown on the Display Screen regarding Printhead replacement.
696 Maintenance
To Next Page
