<007: ATT transmission level>
Use it to set the transmission level (ATT).
Raise the transmission level if errors occur frequently at time of communication because of
the condition of the line. (It means close to 8)
MEMO:
Any of the following error codes may be indicated at time of transmission because of
the line condition:
##100, ##101, ##102, ##104, ##201, ##280, ##281, ##282, ##283, ##284, ##750,
##752, ##754, ##755, ##757, ##759, ##760, ##762, ##764, ##765,
##767, ##769, ##770, ##772, ##774, ##775, ##777, ##779, ##780, ##782, ##784,
##785, ##787, ##789
Any of the following error codes may be indicated at time of reception because of the
line condition:
##103, ##106, ##107, ##201, ##793
##103, ##106, ##107, ##201, ##793
●
<008: V.34 modulation speed upper limit>
Use it to set an upper limit to the modulation speed (baud rate) for the V.34 primary
channel.
●
<009: V.34 data speed upper limit>
Use it to set an upper limit to the data transmission speed for the V.34 primary channel
between 2.4K and 33.6K bps in increments of 2400 bps. (0: 2.4K to 13:33.6K bps).
●
<010: Frequency of the pseudo CI signal>
You may select a frequency for the pseudo CI signal.
Some types of external telephones do not ring when the fax/tel switch-over function is ON.
To sound the ring, change the pseudo CI signal.
#NUMERIC
■
Numerical Parameter Composition
No. Item Range of settings
002 RTN transmission condition(1) 1% to 99%
003 RTN transmission condition (2) 2 to 99 item
004 RTN transmission condition (3) 1 to 99 lines
005 NCC pause time length (pre-ID code) 1 to 60 sec
006 NCC pause time length (post-ID code) 1 to 60 sec
010 line condition identication time length 0 to 9999 (10 msec)
011 T.30T1 timer (for reception) 0 to 9999 (10 msec)
013 T.30 EOL timer 500 to 3000 (10 msec)
015 hooking detection time length 0 to 999
016 time length to rst response at time of fax/tel switchover 0 to 9
017 pseudo RBT signal pattern ON time length 0 to 999
018 pseudo RBT signal pattern OFF time length (short) 0 to 999
019 pseudo RBT signal pattern OFF time length (long) 0 to 999
020 pseudo CI signal pattern ON time length 0 to 999
021 pseudo CI signal pattern OFF time length (short) 0 to 999
022 pseudo CI signal pattern OFF time length (long) 0 to 999
023 CNG detection level at time of fax/tel switchover 0 to 7
024 pseudo RBT transmission level at time of fax/tel switchover 10 to 20
0 to 20 (120/230V)
025 Answering machine connection function signal detection time 0 to 999
027 preamble detection time length for V21 low-speed ag 20 (x 10ms)
051 Hooking detection threshold
053 Setting of DTMF call origination count at remote reception of fax
054 Setting of busy tone output time when handset is used
055 acquisition period of environmental log data 0 to 480 (60min)
056 display the type of soft counter 1 101 (Fixed)
057 Display the type of soft counter 2 0 to 999
058 Display the type of soft counter 3 0 to 999
059 Display the type of soft counter 4 0 to 999
060 Display the type of soft counter 5 0 to 999
061 Display the type of soft counter 6 0 to 999
074 e-RDS RGW port number
075 Interval of transmission for e-RDS 3rd party
T-8-28
