8
8
8-19
8-19
#SCAN
■
Setting of Scanner Functions (SCANNER)
Item1 No.
Initial
setting
Range of settings Function
#SCAN SW Not used
#SCAN
NUMERIC
001: - 032:
033: 50 Vertical scan magnication correction
(scanning on BOOK)
034: 50 Horizontal scan magnication
correction (scanning on BOOK)
035: - 046: Not used
047: 50 Vertical scan magnication correction
(scanning on ADF)
048: 50 Horizontal scan magnication
correction (scanning on ADF)
049: - 192: Not used
193: 0 0: LEGAL
1: FOOLSCAP
2: M_OFICIO
3: A_FOOLSCAP
4: FOLIO
5: G_LEGAL
6: A_OFICIO
7: B_OFICIO
8: OFICIO
9: E_OFICIO
ADF special paper, standardized size:
LGL
misidentication-ready
194: 0 0: LTR
1: G_LTR
2: A_LTR
ADF special paper, standardized size:
LTR
misidentication-ready
195: 0 0: LTR_R
1: FOOLSCAP
2: OFFICIO
3: E_OFFICIO
4: G_LTR_R
5: A_LTR_R
ADF special paper, standardized size:
LTR_R
misidentication-ready
196: - 290: Not used
T-8-31
Item1 Item2 Item3 Item4
Initial
setting
Appropriate
guideline
Description
READER DISPLAY CCD TARGET-B Target value of shading for
blue
TARGET-G Target value of shading for
green
TARGET-R Target value of shading for
red
OFST Not used
OFST-B Adjustment value of offset
level on CCD (blue)
OFST-G Adjustment value of offset
level on CCD (green)
OFST-R Adjustment value of offset
level on CCD (red)
OFST-O Adjustment value of offset
level in odd bit on CCD
OFST-E Adjustment value of offset
level in even bit on CCD
GAIN Not used
GAIN-B Adjustment value of gain
level on CCD (blue)
GAIN-G Adjustment value of gain
level on CCD (green)
GAIN-R Adjustment value of gain
level on CCD (red)
GAIN-O Adjustment value of gain
level in odd bit on CCD
GAIN-E Adjustment value of gain
level in even bit on CCD
IO R-CON Firmware version of reader
controller PCB
FEEDER ROM version of DADF
controller PCB
ADJUST ADJ-XY ADJ-X 20 1 to 211,
1=0.1mm
Adjustment of scanning
system image lead edge
position (image's scan-start
position in vertical scanning
direction)
ADJ-Y 79 1 to 254,
1=0.1mm
Adjustment value of
image scan-start position
<Y-direction>
ADJ-S 121 25 to 500,
1=0.1mm
Adjustment of CCD/CIS
scan-start cell position
(image scan-start position
in horizontal scanning
direction)
ADJ-Y-DF 79 1 to 254,
1=0.1mm
Adjustment of horizontal
scanning position at feeder
mode
