Chapter 1
1-41
4. Contact of Linear Scale/Carriage Shaft
Please do not touch a linear scale and the carriage shaft when the inside of the top cover is opened, and execute maintenance.
When touching a linear scale and the carriage shaft, it might cause defective movement of the carriage and a defective print.
F-1-34
[1] Linear Scale
[2] Carriage Shaft
5. Handling the Maintenance Cartridge
When removing the maintenance cartridge form the printer, use caution so that waste ink does not spatter.
6. Refilling the Printer with Ink
After removing the ink from inside the printer using the automatic or manual ink draining procedure to disassemble/reassemble or transport the printer, refill the
printer with ink as soon as possible upon completion of the work.
If the ink remaining in the printer dries up, mechanical parts may be seized and malfunction may result.
[1][2]
