Canon LBP6670dn Series - Remove the Sleep Interface PCB; Remove the Duplex Reverse Sensor Unit

3
3
3-14
3-14
Disassembly/Assembly > Controller System > Remove the Duplex Reverse Sensor Unit
Disassembly/Assembly > Controller System > Remove the Duplex Reverse Sensor Unit
Remove the Sleep Interface PCB
Preparations
1) Remove Left Cover.(Refer to page 3-9)
Procedure
1) Remove Power Supply PCB [1].
• 6 Connectors [2]
• 1 Wire Saddle [3]
• 1 Screw [4]
• 1 Tab [5]
[1]
[2]
[2]
[2]
[4] [4]
[5] [5]
x2
x6
[3]
F-3-17
Remove the Duplex Reverse Sensor Unit
Preparations
1) Remove Left Cover.(Refer to page 3-9)
2) Remove Right Cover.(Refer to page 3-9)
3) Remove Rear Cover Unit.(Refer to page 3-10)
Procedure
1) Remove Duplex Reverse Sensor Unit [1].
• 1 Screw [2]
• 1 Connector [3]
[1]
[2]
[3]
F-3-18
