Canon LBP6670dn Series - List of Main Unit

3
3
3-3
3-3
Disassembly/Assembly > List Of Parts > List of Main Unit
Disassembly/Assembly > List Of Parts > List of Main Unit
List of Main Unit
[1]
[2]
[3]
[4]
[5]
[6]
[10]
[11]
[7]
[8]
[9]
F-3-1
[12]
[13]
No. Name Reference
[1] Fixing Unit (Refer to page 3-27)
[2] Laser Scanner Unit (Refer to page 3-24)
[3] Registration Unit (Refer to page 3-25)
[4] Multi-purpose Separation Pad (Refer to page 3-31)
[5] Multi-purpose Pickup Roller (Refer to page 3-30)
[6] Transfer Roller (Refer to page 3-25)
[7] Duplex Drive Unit (Refer to page 3-21)
[8] Main Drive Unit (Refer to page 3-20)
[9] Cassette Pickup Roller (Refer to page 3-29)
[10] Cassette Separation Pad (Refer to page 3-30)
[11] Duplex Feed Unit (Refer to page 3-10)
[12] Control Panel (Refer to page 3-18)
[13] Main Controller Board (Refer to page 3-12)
T-3-2
