Troubleshooting
No.1
Symptom: A communication test (COM-TEST) has failed.
Cause: Initial settings or network conditions is incomplete.
Remedy 1: Check and take actions mentioned below.
1) Check network connections
Is the status indicator LED for the HUB port to which the main unit is connected ON?
YES: Proceed to Step 2).
NO: Check that the network cable is properly connected.
2) Conrmation from another PC connected to same network.
Request the user to ping the main unit from a PC connected to same network.
Does the main unit respond?
YES: Proceed to Step 3).
NO: Conrm the details of the main unit's IP address and subnet mask settings.
3) Conrm DNS connection
(a) Take a note of both primary and secondary DNS server addresses.
See Users’ Guide for detailed procedures.
(b) Use ping command to conrm the primary DNS server IP address against the note
taken in Step (a).
See Users’ Guide for detailed procedures.
Is the IP address properly congured?
YES: Proceed to Remedy 2.
NO: Conrm the secondary DNS server IP address against the note taken in Step (a).
Is the IP address properly congured?
YES: Proceed to Remedy 2.
NO: There is a possibility that the DNS server address is wrong. Reconrm the
address with the user's system administrator.
Remedy 2: Troubleshooting using communication log (COM-LOG)
1) Start [Service Mode].
2) Select [NETWORK GR.] > [E-RDS] > [COM-LOG] and press [OK] or [ ] button to display
List Communication Log screen.
E-RDS
COM-LOG
RGW-ADDRESS
RGW-PORT
COM-TEST
COM-LOG
4 CODE : 840f0003
1 CODE : 810f200b
2 CODE : 840f0003
3 CODE : 840f0003
NOTE:
• Only the initial part of error information is displayed in the communication log list screen.
• "None." is shown when nothing is logged.
3) Select the log of your interest and press [OK] or [ ] button to show the date and time of
the error occurrence.
COM-LOG
2010 0413 10:17
4) Press [OK] or [ ] button to show the detailed error information.
COM-LOG
*Server address resolu
F-2-140
F-2-141
F-2-142
