Canon LBP6670dn Series User Manual

3
3
3-19
3-19
Disassembly/Assembly > Controller System > Removing the Main Fan
Disassembly/Assembly > Controller System > Removing the Main Fan
Removing the Main Motor
Preparations
1) Remove Left Cover.(Refer to page 3-9)
2) Remove Right Cover.(Refer to page 3-9)
3) Remove Rear Cover Unit.(Refer to page 3-10)
4) Remove Engine Controller Board.(Refer to page 3-16)
5) Remove Fixing Unit.(Refer to page 3-27)
Procedure
1) Remove Main Motor [2].
2) Pull Transport Unit [3] towards the front.
x3
x2
[1]
[2]
[3]
[4]
[4]
F-3-30
Removing the Main Fan
Preparations
1) Remove Left Cover.(Refer to page 3-9)
2) Remove Right Cover.(Refer to page 3-9)
3) Remove Rear Cover Unit.(Refer to page 3-10)
4) Remove Upper Cover Unit.(Refer to page 3-11)
Procedure
1) Remove grounding spring [1].
2) Remove Main Fan [4].
• 2 screws [2]
• 1 Connector [3]
[4]
[2]
[2][3]
x2
[1]
F-3-31

Canon LBP6670dn Series Specifications

General

Print Technology	Laser
Maximum Resolution	Up to 1200 x 1200 dpi
Duty Cycle	Up to 50, 000 pages per month
Media Types	Plain paper, Heavy Paper, Transparency, Label, Envelope
Duplex Printing	Yes
Network Ready	Yes
Operating System Compatibility	Windows, Mac OS, Linux
Memory	128 MB
Control Panel	5-line LCD
Category	All-in-One Printer
Paper Input (Standard)	250 sheets
Paper Output	150 sheets (face down)
Media Sizes	A4, A5, B5, Legal, Letter, Executive, Envelope
Media Weights	Cassette: 60 to 120 g/m², Multi-purpose tray: 60 to 163 g/m²
Interface Type	USB 2.0
Dimensions (W x D x H)	400 mm x 376 mm x 289 mm
Print Speed (Black)	Up to 35 ppm (A4)
