Front View
A: Paper Support
Extend to load paper in the rear tray.
B: Rear Tray Cover
Open to load paper in the
rear tray.
C: Rear Tray
Load paper here. Two or more sheets of the same size and type of paper can be loaded at the same
time, and fed automatically one sheet at a time.
Loading Paper in the Rear Tray
Loading Envelopes in Rear Tray
D: Paper Guides
Align with both sides of the paper stack.
E: Paper Guides
Align with right/left/front sides of the paper stack.
F: Cassette
Load A4, B5, A5, or Letter-sized plain paper into the
cassette, and insert it into the printer.
Loading Paper in the Cassette
G: Paper Output Tray
Printed paper is ejected.
Pull out it before printing.
H: Operation Panel
Use to change the settings of the printer or to operate it.
Operation Panel
