Canon MVX10 - System Diagram

156
Additional
Information
E
System Diagram
(Availability differs from area to area)
MultiMediaCard
IFC-300PCU USB Cable
PC Card Adapter
USB Reader/Writer
WL-D81 Wireless
Controller
MiniDV
Video
Cassette
CA-570 Compact
Power Adapter
CA-400 Compact
Power Adapter
CA-410 Compact
Power Adapter
CB-400 Car Battery
Adapter
SC-1000 Soft
Carrying Case
Computer
BP-400 Series
Battery Pack
BP-400 Series
Battery Pack
WD-H30.5
Wide-converter
FS-30.5U
Filter Set
TL-H30.5
Tele-converter
SDC-128M
SD Memory Card
TV
VCR
S-150 S-video Cable
Digital Device
STV-250N
Stereo Video Cable
PC-A10 SCART
Adapter
CV-150F/CV-250F DV Cable
Canon printers with direct print function/
PictBridge-compliant printers
SA-1 Adapter Bracket
BP-900 Series
Battery Pack
VL-10Li Battery
Video Light
Stereo Microphone
(commercially available)
