Vision Edition Settings
With a sample program, this chapter describes how to configure the Vision Edition image
processing settings.
● (1) Add a Sample JOB
Create the first image processing setting file (JOB).
● (2) Register the Camera
Use the IP address, user name, and password configured in Chapter 1 to register
the camera.
● (3) Edit the Flowchart
Create a flowchart for the image processing. Use 2D code recognition in
this example.
● (4) Configure Capture Settings and Register a Master Image
Configure the capture parameters and register a master image.
● (5) Edit the 2D Code Recognition Unit
Configure the 2D code recognition region and parameters.
● (6) Configure the Display Options
Configure the display options, such as showing the recognition results.
