Canon VB-H45 Specifications

General

Full HD	Yes
Total megapixels	2.1 MP
Maximum resolution	1920 x 1080 pixels
Video compression formats	H.264
Supported graphics resolutions	320 x 180, 320 x 240, 480 x 270, 640 x 360, 640 x 480 (VGA), 960 x 540, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080)
Digital zoom	40 x
Optical zoom	20 x
Focal length range	4.7 - 94 mm
Maximum aperture number	3.5
Minimum aperture number	1.6
Form factor	Dome
Mounting type	Ceiling
Product color	Silver
Type	IP security camera
PTZ modes	Digital PTZ
Certification	EN55032 Class B, FCC part15 subpart B Class B, ICES-003 Class B, VCCI Class B, RCM AS/NZS EN55032 Class B, CNS13438 Class B, KN22 Class B, EN55024, KN24, EN50581, IEC/UL/EN60950-1
Placement supported	-
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
Connectivity technology	Wired
Number of users	30 user(s)
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x, IEEE 802.3at
Ethernet LAN (RJ-45) ports	1
Audio formats supported	G.711
AC input voltage	24 V
DC output voltage	12
Power source type	AC, DC, PoE
Power consumption (max)	9.9 W
Power consumption (typical)	8.6 W
Power consumption (Power over Ethernet (PoE))	9.2 W
Pan speed	150 °/sec
White balance	Auto, Daylight, Fluorescent, Halogen, Manual, Mercury lamp, Sodium lamp
Camera shutter speed	1 - 1/6000 s
Minimum illumination	0.003 lx
Behavior analysis	Object removal detection
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Sensor type	CMOS
Optical sensor size	1/3 \
Effective sensor resolution	- pixels
Security algorithms	EAP-MD5, EAP-PEAP, EAP-TLS, EAP-TTLS, IPSec, SNMP, SNMPv3, SSL/TLS
Alert notification type	E-mail
Intelligent Video Surveillance (IVS) system features	Abandoned object, Intrusion
Audio input	3.5mm
Built-in HDD	No
Compatible memory cards	SD, SDHC, SDXC

Weight and Dimensions

Height	155 mm
Weight	1140 g
Diameter	132 mm
