26
Make sure that the devices and cables are connected as shown in the following figure.
Double-check to make sure that all cables are connected securely.
6
Turn ON the power to the image processing controller. (Flip the switch to the [I] position.)
Confirm that the green LED light comes on, and that an image appears on the display.
7
DC 24 V
power supply
PoE Hub
IP address:
192.168.0.100
IP address:
192.168.0.2
2
