Canton Smart Soundbox 3 - Connection Terminal

3
57
English
Connection Terminal
1
Ethernet (RJ45 Socket, 8-pole)
2
Analogue Input L/R (3.5mm jack socket, stereo, max. 2Vrms)
3
Power Input (IEC C8, 100-240V~, 50/60Hz, max. 50W)
Phys. Input
LIN
Bluetooth
®
Network (WiFi/Ethernet)
Display indication
AUX
BT
NET
Note: The physical inputs have the following designations:
1
2
3
