Carel humiSonic Compact - Accessories; Atomised Water Distribution; Atomised Water Distributor

10
ENG
“Ultrasound for fancoil” +0300059IE - rel. 1.7 - 24.10.2022
5. ATOMISED WATER DISTRIBUTION
5.1 Atomised water distributor
NOTICE: the atomised water delivery hose, the distributor, the fan conveyor,
the elbow connection and the diuser are not supplied with the humidier.
Code Lenght (mm)
UUKDP02500 250
UUKDP05300 530
UUKDP06100 610
UUKDP08500 850
Requirements:
• humidier delivery hose Øext 40mm;
• make sure the atomised water outlet area is 1100 mm2 (e.g. 22 holes
8 mm in diameter);
• if the customer has to provide a distributor with dierent length, it is
important to respect a maximum length of 1m. For greater lengths,
please contact the Service Department Carel;
• the hose running to the distributor should have a minimum upward
gradient of 2° so that any condensate ows back into the humidier or
a special condensate drain system;
• make sure there are no condensate leaks from the water vapour
distributor;
• position the distributor in such a way that the air is not directed against
nearby objects (minimum distance 10 cm);
• bends or choking of the hose may cause condensate to form and
decrease humidity delivery;
• avoid loads that may cause mechanical stress on the humidier outlet
connector.
Fig. 5.a
Fig. 5.b
5.2 Accessories
Fan conveyor
Fig. 5.c
The air ow conveyor UUKCY00000 can be installed on the top of the fan
(removing the protection grill) so as to take in air from a dierent place to
where humiSonic is installed.
Elbow connector
Fig. 5.d
The elbow connector UUKHS00000 can be installed on the cover and/or the
fan conveyor, so as to reduce the overall height occupied by the product.
Diuser
Fig. 5.e
The diuser UUKDF00000 can be installed on the cover, so as to deliver
atomised water directly into the room.
Filter: 50 micron
Fig. 5.f
A lter UUKFL00000 is available to be installed on the fan, using the conveyor
(with or without the elbow). The lter is delivered disassembled (cap not
xed) because on one side it is possible to mount it on the conveyor, on the
other side on the elbow (to mount with a slight interference). Once mounted,
insert the cap. It’s necessary to clean the lter (with compressed air or running
water) periodically: frequency depends on the environment in which the
system is installed.
Features lter: 50 micron, H = 13 cm, D = 5 cm
Hose (cod. UUKPE00100)
