“Ultrasound for fancoil” +0300059IE - rel. 1.7 - 24.10.2022
10.4 Read-only parameters
Parameter UOM range def note
d0 Th probe temperature reading °C/°F 0-1000 0
d1 Th probe humidity reading %rH 0-1000 0
d2 Congurable input reading (optional card) % / %rH 0-100 0
d3 Tank operating hour counter (resettable, see "Reset
hour counter from display")
h 0-9999(*) 0
d4 Unit hour counter (read-only) h 0-9999(*) 0
d5
Instant production % 0...100 0
d6
Time remaining to end of piezoelectric transducer life h 0...9999(*) 9999 equal to AF - piezoelectric transducer hour counter
d7 Manage secondary unit production - 0...1 0 R/W parameter:
0 = the secondary exactly replicates the production of the main, as it depends
on the setting of parameter P0 on the main;
1 = the secondary produces according to the request sent by the main and its
own P0 setting; it is not aected by the setting of P0 on the main
d8 Dew point temperature
°C/°F 0…1000 0
calculated using d0 and d1
Tab. 10.e
(*) after 999 the display shows to indicate the 1000s (the three digits are displayed with a dot at the top between the rst and second digit).
11. HUMIDIFIER CONTROL VIA NETWORK
The variables shown in the list are a set of all the internal variables. DO NOT CONFIGURE ANY VARIABLES THAT ARE NOT SHOWN IN THE TABLE, OTHERWISE
HUMIDIFIER OPERATION MAY BE AFFECTED.
The serial connection (M11) is congured by default with the following parameters:
- Address 1
- Baud rate 19200 bps
- Frame 8,N,2 (not modiable)
NOTICE:
it is recommended to set on the supervisor (main) the maximum waiting time for a response from humiSonic - after being queried by the supervisor - of
at least 500 ms.
11.1 Supervisor variable list
“A”
analogue variables* (Modbus®: HOLDING REGISTERS) R/W
CAREL - Modbus®
1 1 param. d0: Th probe temperature reading R
2 2 param. d1: Th probe humidity reading R
3 3 param. d2: Probe reading R
4 4 param. d5: Instant production R
9 9 param. d8: Dew point temperature R
“I”
integer variables (Modbus®: HOLDING REGISTERS) R/W
CAREL Modbus®
1
129
Level access password R/W
7
135
Humidier status
0=disabled/standby
1=autotest
2=initialisation
3=ll
4=production
5=drain
6=reset alarms
7=washing
8=cleaning procedure
R
2
130
Firmware release R
15
143
Alarms, refer to Chap.ALARMS:
• bit0: Alarm E0
• bit1: Alarm Et
• bit2: Alarm EF
• bit3: Alarm Ed
• bit4: Alarm EP
• bit5: Alarm PU
• bit6: Alarm H ¯
• bit7: Alarm H_
• bit8: Alarm EE
• bit9: Alarm CL
• bit10: Alarm ES1
• bit11: Alarm ES2
• bit12: Alarm ES3
• bit13: Alarm OFL
• bit14: Alarm EL
• bit15: Alarm EtL
R/W
20
148
Parameter A0: Operating mode R/W
21
149
Parameter A2: Type of external probe R/W
22
150
Parameter A3: Probe minimum R/W
23
151
Parameter A4: Probe maximum R/W
24
152
Parameter A5: Probe oset R/W
25
153
Parameter A6: Duration of fan active with production in standby for tank drying R/W
26
154
Parameter A7: Fan speed R/W
27
155
Parameter A8: Maximum evaporation time for no production alarm R/W
28
156
Parameter A9: Minimum evaporation time for management of discharge leakage R/W
29
157
Parameter b0: Operating options R/W
30
158
Parameter b1: Time between two washing cycles R/W
31
159
Parameter b2: Inactivity time for washing on next start R/W
32
160
Parameter b3: Washing time: duration of the loading and unloading phases active at the same time R/W
33
161
Parameter b4: Start delay time R/W
34
162
Parameter b5: Operating hours for CL alarm R/W
35
163
Parameter b6: Time to display new CL alarm in minutes R/W
36
164
Parameter b7: Transducer On/O control interval R/W
37
165
Parameter b8: Probe delay disconnected R/W
