23
ITA
“Ultrasound for fancoil” +0300059IE - rel. 1.7 - 24.10.2022
b0 1. Unità di
misura del
parametro b1
M = minuti;
H = ore
2. Abilitazione funzionalità
backup
3. Elettrovalvo-
la di scarico in
standby
4. Attivazione Relè
allarme
AL= presenza allarmi
SP= setpoint raggiunto
5. Logica Relè Allarme
NO= norm. aperto
NC= norm. chiuso
6. Abilitazione
lavaggio per
inattività
7. Off = lavaggio per
inattività avviene al
prossimo avvio
On= lavaggio per inatti-
vità avviene regolarm.
8. Auto- test
180 H OFF Closed SP NO Off On Off
181 H OFF Closed SP NO Off On On
182 H OFF Closed SP NO On On Off
183 H OFF Closed SP NO On On On
184 H OFF Closed SP NC Off Off Off
185 H OFF Closed SP NC Off Off On
186 H OFF Closed SP NC On Off Off
187 H OFF Closed SP NC On Off On
188 H OFF Closed SP NC Off On Off
189 H OFF Closed SP NC Off On On
190 H OFF Closed SP NC On
On Off
191 H OFF Closed SP NC On On On
192 H ON Open AL NO Off Off Off
193 H ON Open AL NO Off Off On
194 H ON Open AL NO On Off Off
195 H ON Open AL NO On Off On
196 H ON Open AL NO Off On Off
197 H ON Open AL NO Off On On
198 H ON Open AL NO On On Off
199 H ON Open AL NO On On On
200 H ON Open AL NC Off Off Off
201 H ON Open AL NC Off Off On
202 H ON Open AL NC On Off Off
203 H ON Open AL NC On Off On
204 H ON Open AL NC Off On Off
205 H ON Open AL NC
Off On On
206 H ON Open AL NC On On Off
207 H ON Open AL NC On On On
208 H ON Open SP NO Off Off Off
209 H ON Open SP NO Off Off On
210 H ON Open SP NO On Off Off
211 H ON Open SP NO On Off On
212 H ON Open SP NO Off On Off
213 H ON Open SP NO Off On On
214 H ON Open SP NO On On Off
215 H ON Open SP NO On On On
216 H ON Open SP NC Off Off Off
217 H ON Open SP NC Off Off On
218 H ON Open SP NC On Off Off
219 H ON Open SP NC On Off On
220 H ON Open SP
NC Off On Off
221 H ON Open SP NC Off On On
222 H ON Open SP NC On On Off
223 H ON Open SP NC On On On
224 H ON Closed AL NO Off Off Off
225 H ON Closed AL NO Off Off On
226 H ON Closed AL NO On Off Off
227 H ON Closed AL NO On Off On
228 H ON Closed AL NO Off On Off
229 H ON Closed AL NO Off On On
230 H ON Closed AL NO On On Off
231 H ON Closed AL NO On On On
232 H ON Closed AL NC Off Off Off
233 H ON Closed AL NC Off Off On
234 H ON Closed AL NC On Off Off
235 H ON Closed
AL NC On Off On
236 H ON Closed AL NC Off On Off
237 H ON Closed AL NC Off On On
238 H ON Closed AL NC On On Off
239 H ON Closed AL NC On On On
240 H ON Closed SP NO Off Off Off
241 H ON Closed SP NO Off Off On
242 H ON Closed SP NO On Off Off
243 H ON Closed SP NO On Off On
244 H ON Closed SP NO Off On Off
245 H ON Closed SP NO Off On On
246 H ON Closed SP NO On On Off
247 H ON Closed SP NO On On On
248 H ON Closed SP NC Off Off Off
249 H ON Closed SP NC Off Off On
250 H ON
Closed SP NC On Off Off
251 H ON Closed SP NC On Off On
252 H ON Closed SP NC Off On Off
253 H ON Closed SP NC Off On On
254 H ON Closed SP NC On On Off
255 H ON Closed SP NC On On On
Tab. 10.c
10.3 Parametri collegamento seriale
Parametro UM range def note
C1 Baud rate
0 = 4800 bps; 1 = 9600 bps; 2 = 19200 bps; 3 = 38400 bps
- 0...3 2
C2 Indirizzo tLan (se 0 = Main)
C3 indirizzo seriale - 1...207 1
C4 Timeout per generazione allarme offline Main seriale s 0...240 30 L’allarme viene generato solo se è attivo il controllo della
produzione via rete (vedere cap. "Collegamento in rete")
Tab. 10.d
