“Ultrasound for fancoil” +0300059IE - rel. 1.7 - 24.10.2022
b0 1. Unit of
measure of
parameter b1
M = minutes;
H = hours
2. Enable backup function 3. Drain sole-
noid valve in
standby
4. Alarm relay activation
AL= alarms present
SP= set point reached
5. Alarm relay logic
NO= norm. open
NC= norm. closed
6. Enable wash
due to inactivity
7. O = wash due to
inactivity at next start
On= standard wash due
to inactivity
8. Auto- test
178 H OFF Closed SP NO On O O
179 H OFF Closed SP NO On O On
180 H OFF Closed SP NO O On O
181 H OFF Closed SP NO O On On
182 H OFF Closed SP NO On On O
183 H OFF Closed SP NO On On On
184 H OFF Closed SP NC O O O
185 H OFF Closed SP NC O O On
186 H OFF Closed SP NC On O O
187 H OFF Closed SP NC On O On
188 H OFF Closed SP NC O On O
189 H OFF
Closed SP NC O On On
190 H OFF Closed SP NC On On O
191 H OFF Closed SP NC On On On
192 H ON Open AL NO O O O
193 H ON Open AL NO O O On
194 H ON Open AL NO On O O
195 H ON Open AL NO On O On
196 H ON Open AL NO O On O
197 H ON Open AL NO O On On
198 H ON Open AL NO On On O
199 H ON Open AL NO On On On
200 H ON Open AL NC O O O
201 H ON Open AL NC O O On
202 H ON Open AL NC On O O
203 H ON Open AL NC On O On
204 H
ON Open AL NC O On O
205 H ON Open AL NC O On On
206 H ON Open AL NC On On O
207 H ON Open AL NC On On On
208 H ON Open SP NO O O O
209 H ON Open SP NO O O On
210 H ON Open SP NO On O O
211 H ON Open SP NO On O On
212 H ON Open SP NO O On O
213 H ON Open SP NO O On On
214 H ON Open SP NO On On O
215 H ON Open SP NO On On On
216 H ON Open SP NC O O O
217 H ON Open SP NC O O On
218 H ON Open SP NC On O O
219
H ON Open SP NC On O On
220 H ON Open SP NC O On O
221 H ON Open SP NC O On On
222 H ON Open SP NC On On O
223 H ON Open SP NC On On On
224 H ON Closed AL NO O O O
225 H ON Closed AL NO O O On
226 H ON Closed AL NO On O O
227 H ON Closed AL NO On O On
228 H ON Closed AL NO O On O
229 H ON Closed AL NO O On On
230 H ON Closed AL NO On On O
231 H ON Closed AL NO On On On
232 H ON Closed AL NC O O O
233 H ON Closed AL NC O O On
234 H ON Closed AL NC On O O
235 H ON Closed AL NC On O On
236 H ON Closed AL NC O On O
237 H ON Closed AL NC O On On
238 H ON Closed AL NC On On O
239 H ON Closed AL NC On On On
240 H ON Closed SP NO O O O
241 H ON Closed SP NO O O On
242 H ON Closed SP NO On O O
243 H ON Closed SP NO On O On
244 H ON Closed SP NO O On O
245 H ON Closed SP NO O On On
246 H ON Closed SP NO On On O
247 H ON Closed SP NO On On On
248 H ON Closed SP NC O O
O
249 H ON Closed SP NC O O On
250 H ON Closed SP NC On O O
251 H ON Closed SP NC On O On
252 H ON Closed SP NC O On O
253 H ON Closed SP NC O On On
254 H ON Closed SP NC On On O
255 H ON Closed SP NC On On On
Tab. 10.c
10.3 Serial connection parameters
Parameter UOM range def note
C0 Default display (Terminal) - 0-5 0
C1 Baud rate: 0 = 4800 bps; 1 = 9600 bps; 2 = 19200 bps; 3 = 38400 bps - 0-3 2
C2 tLAN address (if 0 = main)
C3 Serial address - 1-207 1
C4 Timeout for main oine alarm s 0-240 30 The alarm is only generated if online production control is
active (see chap. "Humidier control via network")
Tab. 10.d
