CAS CL5200J Series - Sensor Calibration (Menu Code 1733)

107
• If it is Ticket Mode, “TICKET SIZE” is displayed, and “TEST” key is not
operated.
And “Feed”, “End Margin” instead of “Height”, “Gap Length” shows up.
EX) Width = 60mm
EX) Feed = 20mm
EX) End Margin = 20mm
• If it is Continuous Label Mode, “CONT. LABEL SIZE” is displayed, and “TEST” key is
not operated. And “End Margin” instead of “Gap Length” shows up.
2.9.3.3 Sensor Calibration (Menu code 1733)
(MENU → 7. Print → 3. Printer Hardware → 3. Sensor Calibration )
Enter appropriate values for “Gap”, “Peel”, “Out of Paper”.
• If you press “TEST” key, Gap and Peel
values are adjusted automatically.
• If it is Ticket mode, “Gap” value is not
saved.
